Product

2/2 Way Plate-type Solenoid Valve

2/2 Way Plate-type Solenoid Valve
Product ID: JBA-NO
  • 2/2 way normally open solenoid valve, forged copper body.
  • It is small in size and widely used in the automatic control of actuators such as cylinders and valves. It is also widely used in the air compressor industry.
Specifications:
  • IP65 waterproof coil, compliant with CE standards.
  • Applicable fluids: water, air, light oil.
Features:
  • Environmental applicable temperature: -20°C ~ 65°C.
  • Applicable fluid temperature: -10°C ~ 130°C. If the heat-resistant temperature needs to be used up to 130°C, there are other seal materials to choose from, please consult the sales personnel.
  • Working pressure: 0~24 kgf/cm².
  • Voltage difference tolerance: ±10%.
See more complete detail
Model Orifice Size CV Operating Pressure kgf/cm² Size (mm) Weight(kg)
Water Air Light Oil L C H B
JBA 1.2 0.06 0~24 0~24 0~18 32 50 70 32 0.29
1.5 0.09 0~20 0~20 0~15 32 50 70 32 0.29
Order Information:
  • Minimum Order: Negotiable
  • Branded Product
